A low-powered AA gun introduced in 1915 for River Monitors. Not considered to be an effective weapon.
Actual bore diameter was 6.6 cm (2.6").
| Designation | 7 cm (2.75") G. L/26 K15 Škoda |
|---|---|
| Ship Class Used On | Monitors: Sava and Wels classes |
| Date Of Design | about 1915 |
| Date In Service | 1916 |
| Gun Weight | 485 lbs. (220 kg) without breech |
| Gun Length oa | 67.5 in 1.715 m) |
| Bore Length | N/A |
| Rifling Length | N/A |
| Grooves | N/A |
| Lands | N/A |
| Twist | N/A |
| Chamber Volume | N/A |
| Rate Of Fire | 15 to 20 rounds per minute |
| Type | Fixed |
|---|---|
| Projectile Types and Weights | HE: 11.7 lbs. (5.3 kg) |
| Bursting Charge | N/A |
| Projectile Length | N/A |
| Propellant Charge | 1.1 lbs. (0.485 kg) |
| Muzzle Velocity | 1,575 fps (480 mps) |
| Working Pressure | N/A |
| Approximate Barrel Life | N/A |
| Ammunition stowage per gun | N/A |
N/A
| Designation | Twin Mounts
Sava (1) Wels (2) |
|---|---|
| Weight | N/A |
| Elevation | About -5 / +85 degrees |
| Elevation Rate | N/A |
| Train | N/A |
| Train Rate | N/A |
| Gun recoil | N/A |
| Loading Angle | Any |
"Naval Weapons of World War One" by Norman Friedman
Original research by Mihály Krámli and András Hatala
15 May 2025 - New datapage
